| Camera | ||
|---|---|---|
| Image Sensor: | | | 1/3” PICADIS |
| Signal System: | | | PAL/NTSC |
| Effective Pixels: | | | 1280 (H) × 960 (V) |
| Min. Illumination: | | | 0.1 Lux @ (F1.2, AGC ON), 0 Lux with IR 0.3 Lux @ (F2.3, AGC ON), 0 Lux with IR |
| Shutter Time: | | | 1/25(1/30) s to 1/25,000(1/30,000) s |
| Lens: | | | 3.6 mm @ F2.3 (2.8mm,6 mm optional) Angle of view: 73.1° (3.6 mm) |
| Lens Mount: | | | M12 |
| Adjustment Range: | | | Pan: 0 – 360°, Tilt: 0 – 90°, Rotation: 0 – 360° |
| Day& Night: | | | IR cut filter with auto switch |
| Horizontal Resolution: | | | 720TVL |
| Synchronization: | | | Internal Synchronization |
| Video Output: | | | 1Vp-p Composite Output (75Ω/BNC) |
| S/N Ratio: | | | More than 62 dB |
| General | ||
| Operating Conditions: | | | -40 °C – 60 °C (-40 °F – 140 °F) Humidity 90% or less (non-condensing) |
| Power Supply: | | | 12 V DC±10% |
| Power Consumption: | | | Max. 1.5 W (Max. 4.5 W with IR cut filter on) |
| Weather Proof: | | | IP66 |
| IR Range: | | | Approx 10 to 20 meters |
| Dimension: | | | Φ70×149.5 mm (Φ2.76” ×5.89”) |
| Weight: | | | 360 g (0.79 lbs) |
| Camera | ||
|---|---|---|
| Image Sensor: | | | 1/3″ Progressive Scan CMOS |
| Signal System: | | | PAL/NTSC |
| Min. Illumination: | | | Color: 0.1 Lux @ (F1.2, AGC ON) B/W: 0.01 Lux @ (F1.2, AGC ON) |
| Shutter time: | | | 1 s to 1/100,000 s |
| Lens Mount: | | | C/CS mount |
| Auto Iris: | | | DC drive(-P: support P-Iris) |
| Day& Night: | | | IR cut filter with auto switch |
| Wide Dynamic Range: | | | 120 dB |
| Digital noise reduction: | | | 3D DNR |
| Focus: | | | ABF(-A model) |
| Compression Standard | ||
| Video Compression: | | | H.264/MPEG4/MJPEG |
| Bit Rate: | | | 32Kbps~16Mbps |
| Audio Compression: | | | G.711/G.722.1/G.726/MP2L2 |
| Triple Streams: | | | Yes |
| Image | ||
| Max. Image Resolution: | | | 2048×1536 |
| Frame Rate: | | | 50Hz: 20fps (2048 × 1536), 25fps (1920 × 1080), 25fps (1280 × 720) 60Hz: 20fps (2048 × 1536), 30fps (1920 × 1080), 30fps (1280 × 720) |
| Third Stream: | | | Independent with Main Stream and Sub Stream, up to 50Hz: 20fps (2048 × 1536) 60Hz: 20fps (2048 × 1536) |
| Image Settings: | | | Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
| BLC: | | | Support |
| Smart Defog: | | | Support |
| EIS: | | | Support |
| ROI: | | | Support |
| Picture Overlay: | | | 128 × 128, BMP 24bit, zone configurable |
| Network | ||
| Network Storage: | | | NAS (Support NFS,SMB/CIFS) |
| Alarm Trigger: | | | Line crossing detection, Intrusion detection, Defocus detection, Scene change detection, Motion detection, Face detection, Dynamic analysis, Tampering alarm, Network disconnect, IP address conflict, Storage exception |
| Protocols: | | | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour(SIP optional) |
| Security: | | | User Authentication, Watermark, IP address filtering, anonymous access, flickerless, heartbeat, video mask |
| System Compatibility: | | | ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI |
| Interface | ||
| Audio Input: | | | 1-ch 3.5 mm audio interface, Mic in/Line in. 1 built-in Microphone |
| Audio Output: | | | 1-ch 3.5mm audio interface (line level, 600 Ω) |
| Communication Interface: | | | 1 RJ45 10M/100M Ethernet port, 1 RS-485 interface and 1 RS-232 interface |
| Alarm Input: | | | 1 |
| Alarm Output: | | | 1 |
| Video Output: | | | 1Vp-p Composite Output (75 Ω, BNC) |
| On-board storage: | | | Built-in Micro SD/SDHC/SDXC card slot, up to 64 GB |
| Reset Button: | | | Yes |
| Wi-Fi Specification (-W) | ||
| Wireless Standards: | | | IEEE802.11b, 802.11g, 802.11n |
| Frequency Range: | | | 2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth: | | | 20/40MHz Support |
| Modulation Mode: | | | 802.11b: CCK, QPSK, BPSK 802.11g/n: OFDM |
| Security: | | | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
| Transmit Power: | | | 11b: 17±1.5dBm @ 11Mbps 11g: 14±1.5dBm @ 54Mbps 11n: 12.5±1.5dBm |
| Receive Sensitivity: | | | 11b: -90dBm @ 11Mbps (Typical) 11g: -75dBm @ 54Mpbs (Typical) 11n: -74dBm (Typical) |
| Transmission Rate: | | | 11b: 11Mbps 11g: 54Mbps 11n: up to 150Mbps |
| Wireless Range: | | | 50m(depend on environment) |
| General | ||
| Operating Conditions: | | | -30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing) |
| Power Supply: | | | 24V AC, ±10% / 12V DC, ±10% , PoE(Power Over Ethernet) |
| Power Consumption: | | | Max. 6.5 W (Max. 9.5 W with IR cut filter on) -W: Max. 7.5 W (Max. 10.5W with IR cut filter on) |
| Dimensions: | | | 69.8×58×145 mm (2.68” × 2.56” × 5.70”) |
| Weight: | | | 830 g (1.83 lbs) |
| Camera | ||
|---|---|---|
| Image Sensor: | | | 1/3” CCD |
| Signal System: | | | PAL/NTSC |
| Effective Pixels: | | | PAL: 976 (H) × 582 (V) NTSC: 976 (H) × 494 (V) |
| Min. Illumination: | | | 0.001 Lux @ (F1.2, AGC ON), 0 Lux with IR 0.002 Lux @ (F1.8, AGC ON), 0 Lux with IR |
| Shutter Time: | | | 1/50(1/60)s to 1/100,000s |
| Lens: | | | 3.6 mm @ F1.8 (6mm,8mm,12mm,16mm optional) Angle of view: 70°(3.6mm) |
| Lens Mount: | | | M12 |
| Day& Night: | | | Electronic |
| Horizontal Resolution: | | | 700 TVL |
| Synchronization: | | | Internal Synchronization |
| Video Output: | | | 1Vp-p Composite Output (75Ω/BNC) |
| S/N Ratio: | | | More than 62 dB |
| BLC: | | | On |
| General | ||
| Operating Conditions: | | | -30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 90% or less (non-condensing) |
| Power Supply: | | | 12 V DC±10% |
| Power Consumption: | | | Max.5 W |
| Weather Proof: | | | IP66 |
| IR Range: | | | Approx 50 to 80 meters |
| Dimension: | | | 105×104.8×263.1mm(4.13” ×4.13” ×10.36”) |
| Weight: | | | 800 g (1.76 lbs) |
| Camera | ||
|---|---|---|
| Image Sensor: | | | 1/4″ Interline Transfer CCD |
| Effective Pixels: | | | PAL:976(H)×582(V) NTSC:976(H)×494(V) |
| Horizontal Resolution: | | | Color: 700 TVL B/W: 750 TVL |
| Signal System: | | | PAL/NTSC |
| Min.illumination: | | | Color: 0.02Lux/(F1.6, AGC ON),0.0008Lux /(F1.6, AGC ON, IRE×256) B/W: 0.002Lux/(F1.6, AGC ON),0.00008Lux /(F1.6, AGC ON, IRE×256) 0 Lux with IR |
| White Balance: | | | Auto / Manual / ATW / Indoor / Outdoor |
| AGC: | | | Auto/Manual |
| S/N Ratio: | | | ≥ 50dB |
| DNR: | | | 3D DNR |
| BLC: | | | ON/OFF |
| Shutter time: | | | PAL: 1/3 ~ 1/10,000s, NTSC: 1/4 ~ 1/10,000s |
| Day&Night: | | | ICR |
| Digital Zoom: | | | 16x |
| Privacy Masking: | | | 8 privacy masks programmable; a maximum of 8 zones can be masked simultaneously on the same video screen |
| Focus Mode: | | | Auto / Semi-automatic / Manual |
| Lens | ||
| Focal Length: | | | 3.3-119mm, 36X |
| Zoom Speed: | | | Approx.4.4s(Optical Wide-Tele) |
| Angle of View: | | | 57.1°-1.7°(Wide-Tele) |
| Aperture Range: | | | F1.4 – F4.2 |
| Pan & Tilt | ||
| Pan Range: | | | 360° endless |
| Pan Speed: | | | Pan Manual Speed: 0.1° -160°/s, Pan Preset Speed: 240°/s |
| Tilt Range: | | | -2°-90° (Auto Flip ) |
| Tilt Speed: | | | Tilt Manual Speed: 0.1°-120°/s, Tilt Preset Speed: 200°/s |
| Proportional Zoom: | | | Rotation speed can be adjusted automatically according to zoom multiples |
| Number of Preset: | | | 256 |
| Patrol: | | | 8 patrols, up to 32 presets per patrol |
| Pattern: | | | 4 patterns, with the total recording time not less than 10 minutes |
| Power-off Memory: | | | Support |
| Park Action: | | | Preset / Patrol / Pattern / Pan scan / Tilt scan / Frame Scan / Random scan / Panorama scan |
| PTZ Position Display: | | | ON/OFF |
| Freeze Frame: | | | Support |
| Password Protection: | | | Support |
| Zone Scanning/Display: | | | Scanning within programmed zone, display zone title |
| Camera Title: | | | Programmable title display |
| Compass: | | | Support , the north can be set |
| Scheduled Task: | | | Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan |
| RS-485 communication diagnosis: | | | Including failure information, e.g., wrong address, baud rate errors, et., displayed on the video screen in text |
| Manchester code communication diagnosis: | | | Including failure information, e.g., wrong address, baud rate errors, et., displayed on the video screen in text |
| Smart-tracking: | | | Support |
| Infrared | ||
| IR Range: | | | 150m |
| IR irradiation angle: | | | Adjustable by zoom |
| Alarm | ||
| Alarm Input: | | | 2 inputs(7 inputs optional) |
| Alarm Output: | | | 2 relay outputs, alarm response actions option |
| Input & Output | ||
| Monitor Output: | | | 1.0V[p-p] / 75Ω, NTSC (or PAL) composite, BNC |
| General | ||
| Menu Language: | | | English / Chinese |
| RS-485 Protocols: | | | HIKVISION, Pelco-P, Pelco-D, self-adaptive |
| Power Supply: | | | 24V AC |
| Power Consumption: | | | Max. 52W |
| Working Temperature /Humidity: | | | -30 ℃-65℃(-22℉-149℉)(outdoor dome) 90% or less |
| Protection Level: | | | IP66 standard (outdoor dome) TVS 4,000V lightning protection, surge protection and voltage transient protection |
| Wiper: | | | Support |
| Mounting: | | | Various mounting modes option |
| Dimensions: | | | Φ245 ×399mm (Φ9.65” ×15.71” ) (Outdoor) |
| Weight(approx.): | | | 5.5kg(12.13Ibs) |
| Mount Option: | | | Long-arm wall mount: DS-1601ZJ; Corner mount: DS-1633ZJ; Pole Mount: DS-1622ZJ; Power box mount:DS-1634ZJ |
